Dental Scanner – Lodden dental https://www.loddendental.com/en One-stop Digital CAD/CAM Dental Solution Service Provider Wed, 19 Nov 2025 11:14:52 +0000 en-US hourly 1 https://wordpress.org/?v=6.9 https://www.loddendental.com/wp-content/uploads/2024/06/未标题-2-2-150x150.png Dental Scanner – Lodden dental https://www.loddendental.com/en 32 32 DS Series Dental Desktop 3D Model Scanner https://www.loddendental.com/en/product/desktop-3d-scanner-for-dental-labs/ https://www.loddendental.com/en/product/desktop-3d-scanner-for-dental-labs/#respond Wed, 13 Nov 2024 03:47:17 +0000 https://loddendental.com/?post_type=product&p=8933 Grand launch of a series of dental 3D scanners. Ingenious design, with excellent performance to meet the efficiency and precision needs of technicians in all scenarios.

  • 13 scanning full arch
  • 2*5MP HD camera
  • Compatible Exocad, 3shape, and others CAD software
  • Accuracy down to 5μm(ISO 12836)
  • Special design for dental
  • FDA/CE medical Quality and certified

The post DS Series Dental Desktop 3D Model Scanner appeared first on Lodden dental.

]]>

Dental 3D Model Scanner - DS Series

  • 2*HD camera
  • Output.STL, .PLY, .OBJ file
  • Support stone, wax, impression, texture, articulator, and more.
  • Full arch scan in 11s, and the full arch impression scan in 27s
Dental Desktop 3D Model Scanner - Accuracy

Intelligently Optimization for Dental Materials

DS Series Dental Desktop 3D Model Scanner employs advanced, pre-set algorithms specifically engineered for the challenging variety of common dental materials (plaster, metal, wax, articulators). It automates crucial data processing steps—mesh cleaning, hole filling, data compression, and noise removal.

  • True Color Texture
  • Intelligent optimization of metal, wax, plaster,  ariculator, and more
  • Intelligent mesh cleaning, precise hole filling, efficient data compression, and complete removal of floating noise

Binocular High-Precision Camera Array

DS Series Dental 3D Model Scanner integrates Dual High-Precision Cameras boasting 5MP Ultra-High-Definition resolution. Leveraging the latest Structured Blue Light 3D Scanning Technology, it achieves a verified precision of 5μm (0.005mm) or lower(certified ISO 12836 standard). Engineered for efficiency, the combination of a fully automatic rotating platform and high-speed intelligent algorithms allows for an unprecedented full dental arch scan in as little as 13seconds, with full texture mapping completed in 29seconds.

Dental Desktop 3D Model Scanner - HD Camera
LODDEN Scanner Software

Cross-System Compatibility

DS Series Dental Desktop 3D Model Scanner software is a true multi-platform solution, offering universal compatibility across Android, Windows, iOS, and Mac operating systems. It features direct cloud connectivity via Wi-Fi, enabling flexible and modern digital operations. The design emphasizes streamlined workflow and usability, offering one-click functionality for critical tasks such as system calibration and initiating the scanning process. To ensure maximum flexibility within the digital laboratory, the software supports one-click data export into the industry-standard formats of .stl, .ply, and .obj, guaranteeing seamless integration and compatibility with virtually all major CAD software platforms.

Dental Desktop 3D Model Scanner - DS500

  • Camera: 2*5.0MP
  • Accuracy: ≤5 μm(ISO 12836)
  • Output: .STL, .PLY, .OBJ
  • Scan Area:94mm*89mm*60mm
  • Full Arch Scan: Only 13s
  • Full Arch Impression Scan: Only 29s
DS500 3D Scanner
Lodden Dental Desktop 3D Model Scaaner DS300

Dental Desktop 3D Model Scanner - DS300

  • Camera: 2*3.0MP
  • Accuracy: ≤5 μm(ISO 12836)
  • Output: .STL, .PLY, .OBJ
  • Scan Area:94mm*89mm*60mm
  • Full Arch Scan: Only 13s
  • Full Arch Impression Scan: Only 29s

Dental Desktop 3D Model Scanner - DS130

  • Camera: 2*1.3MP
  • Accuracy: ≤7 μm(ISO 12836)
  • Output: .STL, .PLY, .OBJ
  • Scan Area:106mm*84mm*60mm
  • Full Arch Scan: Only 11s
  • Full Arch Impression Scan: Only 27s
Lodden Dental Desktop 3D Model Scanner DS130

Cross-System Compatibility
Model DS130 DS 300 DS 500
Camera Resolution 2*1.3MP 2*3.0MP 2*5.0MP
Accuracy 7μm(ISO12836) 5μm(ISO12836) 5μm(ISO12836)
Full Arch Scan   Speed 11s 13s 13s
Full Arch Impression Scan Speed 27s 29s 29s
Scan Area 106mm*84mm*60mm 94mm*89mm*60mm 94mm*89mm*60mm
Dimension 393mm*271mm*274mm
Weight 9kg
Package Weight 14kg
Package Size 50*40*40cm
Output Format .STL, .PLY, .OBJ
Light Source Blue Light
Texture Scanning True Colour Scanning
Power Supply DC 24V
Interface USB 3.0
Articulator   Scan Dynamic/Static
Support Articulator Transfer

Dental Desktop 3D Model Scanner Solution

Dental Desktop 3D Model Scanner Solution

The post DS Series Dental Desktop 3D Model Scanner appeared first on Lodden dental.

]]> https://www.loddendental.com/en/product/desktop-3d-scanner-for-dental-labs/feed/ 0 Heyinscan S3 Intraoral Scanner https://www.loddendental.com/en/product/heyinscan-s3-intraoral-scanner/ Mon, 21 Oct 2024 10:33:08 +0000 https://loddendental.com/?post_type=product&p=7781 Intraoral scanner Digital implant/orthodontics/restoration Make dental treatment easier:

  • Medical-grade quality
  • Dentist special production
  • Aerospace-grade aluminum alloy case
  • Mini tip size
  • Only 210g in weight
  • Up to 100 times autoclavable
  • Resistance heating defogger
  • True color 3D model
  • Calibration Free
  • Single Arch in 30s
  • Accurate <10μm
  • Digital HD camera real-time check oral
  • Output .STL, .OBJ, .PLY file
  • Cloud real-time synchronization
  • Support 15 languages

The post Heyinscan S3 Intraoral Scanner appeared first on Lodden dental.

]]>

Heyinscan S3 Intraoral Scanner

  • Light Weight
  • Fast Scanning
  • High Accuracy
  • Real-time Images
  • AI-generated Report

Demo Video

Demo Video

LODDEN Heyinscan S3 Intraoral Scanner Details - Scan Header

2 Tip Size

Accommodates adults and children Anti-fogging

19.7mm Standard Tip

Scan Area: 15x15mm

16mm Mini Tip

Scan Area: 12x12mm

Ergonomic Design

Heating Anti-fog

Resistance heating defogger

100 Times

Up to 100 times autoclavable

Only 210g Weight

Easy to single hand hold on
LODDEN Heyinscan S3 Intraoral Scanner Details - Handle Scanner

AI Assisted Scanning

  • Speed Up The Scan
  • More Accurate
  • Metal Scan Optimization

Metal Scan Optimization

Optimized metal scan tools can help dentists scan all kinds of metal materials.
LODDEN Heyinscan S3 Intraoral Scanner Details - Metal Scan Optimization

Faster

  • Single Arch in 30s
  • Full Arch(including Bite Scan) in 90s
LODDEN Heyinscan S3 Intraoral Scanner Details - AI Scan Speed

More Accurate

  • Single Crown <10μm
  • Single Arch <15μm
  • Full Arch <20μm
LODDEN Heyinscan S3 Intraoral Scanner Details - Accurate

AI Analytics

  • HD Camera
  • AI Report
  • Multi Design Platforms

HD Camera

With HD Camera to real-time check intraoral images, and one-click save images or reports.
LODDEN Heyinscan S3 Intraoral Scanner Details - Camera

AI Report

AI can accurately find and locate the lesion, and one-click generate the patient's intraoral health report .
Heyinscan S3 Intraoral Scanner Details - Ai Analytic

Multi Platforms

One click output 3shape, exocad, Aidite3d, and more platforms.
LODDEN Heyinscan S3 Intraoral Scanner Details - Partner LOGO
LODDEN Scanner Software

Cloud Synchronization

Available on windows, android and IOS/MAC real-time cloud synchronization images and reports captured.

Real Cases

Technical Specifications

Heyinscan S3 Intraoral Scanner Specifications
Scanner Dimension(L*W*H) 240mm*49.5mm*30.5mm
Weight 210g
Tip Tip Size Standard Tip: 79mm*19.7mm*15.8mm
Mini Tip: 80mm*16mm*11mm
Scan Area Standard Tip: 15mm*15mm
Mini Tip: 12mm*12mm
Scan Depth 15mm
Autoclavable Up to 100 times
(121°C 6mins/134°C 4mins)
Accuracy Crown <10μm
Full Arch <20μm
Scan Speed Single Arch 30s
Full Arch 90s
Calibration Calibration   Free
Output STL,   OBJ, PLY
Connector USB   3.0
Languages Chinese, English, French, Spanish, Russian, Portuguese, Italian, Greek, Polish, Romanian, Janpanese, Korean.
Recommended PC Configuration
Category Laptop Desktop
CPU Inter Core i7-11700H Inter Core i7-11700
RAM 16Gb or Higher
Graphic Card(GPU) NVIDIA ® RTX 3060 6GB or Higher
(Not Support AMD Graphic Cards)
Hard Disk Drive 256 GB SSD or above
Operating System Windows 10 Professional (64-bit) or later versions of Windows operating systems
Screen Resolution 1920×1080, 60 Hz or Higher

Intraoral Scanner Solution

Intraoral Scanner Solution

The post Heyinscan S3 Intraoral Scanner appeared first on Lodden dental.

]]> Dental Scanner - Lodden dental nonadult
