Heytemp-T6I Press furnace

chris@lddentallab.com — Mon, 18 Nov 2024 07:55:36 +0000

Efficient, convenient, fast, low cost, compatible with all casting ceramic blocks.Built-in a large number of programs, can be used as a ceramic furnace.Servo motor drives die casting, constant pressure, no external air source required, high success rate.

The post Heytemp-T6I Press furnace appeared first on Lodden dental.

Heytemp-T5M Porcelain furnace

chris@lddentallab.com — Mon, 18 Nov 2024 07:53:00 +0000

It can realize functions such as glass ceramic crystallization, glazing, porcelain baking, porcelain filling, dyeing, ring firing, etc. It is small in size, occupies little space, and is very convenient to place and store.

The post Heytemp-T5M Porcelain furnace appeared first on Lodden dental.

HeyTemp TP Series Porcelain Furnace

chris@lddentallab.com — Mon, 18 Nov 2024 07:08:56 +0000

CAM Porcelain Furnace - HeyTemp TP Series

The LODDEN TP Series is engineered to be the essential CAM tool for both dental labs and chairside applications. It delivers precise, predictable results for the crucial processes of glazing Zirconia restorations and sintering Lithium Disilicate and hybrid ceramics.

Dentist Special Furnace

20-40 pcs Denture/90mm Tray
Glazing in 20 mins

AI Intelligent

Pre-drying Zirconia & Ceramic
Heat Distribution
10+ Years Lifes

AI Temperature Control

Heating Speed Up To 200°C/S
Max Temperature in 1200°C
Auto Calibration

Multi-Purpose

Crystallization
Glazing
Baking
Mending
Dyeing
Ring Burning

AI Assisted System

AI Assisted Sintering System

The AI-technically optimized HeyTemp TP Series now extends its versatility to include advanced pre-drying support for Zirconia materials, alongside lithium disilicate and mixed ceramics. The firing cycle begins only after complete moisture evaporation.

Pre-drying Zirconia and Ceramic
Preloaded 50 Firing Programs
Support 150 Customized Cycles

AI Temperature Control System

Auto Calibration Temperature
Maximum Heating Speed 200°C/S
Up to 1200°C Temperature
20-30mins Completed Once Sintering

Porcelain Furnace Parameter


Model	T3P	T4P	T5P
Voltage	110-120V	110-120V	110-120V
Power	1600W	1500W	1500W
Max Temperature	1200°C	1200°C	1200°C
Heating Rate	200°C/min	200°C/min	200°C/min
Capacity	20-40units	20-40units	20-40units
Sintering Times	40-60mins	40-60mins	40-60mins
Calibration	Auto	Auto	Auto
Program	200	200	200
Languages	EN, ES, RU	EN, ES, RU	EN, ES, RU
Interface	USB3.0	USB3.0	USB3.0

Explored More CAM Devices

Dental Press Furnace

Max temperature: 1200°C
Pressing capacity: 5-10 units
Maximum heating speed 200°C/S
Can be used for porcelain furnace

Explored More

HeyTemp Sintering Furnace

150 units/100mm tray*3
Max temp up to 1750°C
Heating speed up to 200°C/S
Easy to use

Explored More

CAM HeyTemp Porcelain Furnace Solution

The post HeyTemp TP Series Porcelain Furnace appeared first on Lodden dental.

Heytemp TS Series Zirocnia Sintering Furnace

chris@lddentallab.com — Tue, 29 Oct 2024 06:32:27 +0000

CAM Zirconia Sintering Furnace - HeyTemp TS Series

Upgrade Heating Rods

Silicon Carbon/Silicon Molybdenum*4
Max Temperature Up To 1750°C
Heating speed up to 200°C/min

Fast/Slow Integrated

Integrating fast sintering and slow sintering as two methods.

Upgrade Crucible

0 Metal Ion Contamination
100mm*3 Crucibles
Up To 150 Units Once Sintering

Upgrade Heating Rods

The fast sintering furnace used silicon carbide as heating rods, and the sintering time was reduced to 1 hour. In contrast, the slow sintering furnace, which uses silicon molybdenum as heating rods, has a lifespan of 500 times its use.

Silicon carbon*4/5 or Silicon molybdenum*4
Max temperature up to 1750°C
Heating speed max to 200°C/min

Upgrade Crucible

Thanks for the heating rods that were graded. The crucible is being upgraded at the same time. The fast sintering furnace used a 60mm crucible, loading 20 units of dentures, once sintering. And the slow furnace used a 3-layer 100mm crucible, so that once sintering can be loaded up to 150 dentures.

Crucible size: 60mm*/90mm*2/100mm*3

Crucible layer: 1/2/3 layers

Crucible lifespan: 100 times used

Easy To Use

Zero learning curve
Auto calibration temperature
Preload 50 standard sintering programs
Silicon carbon/molybdenum rods are easy to replace
15+ years lifespan

Quality, Purity, Simplicity

The TS Series Zirconia Sintering Furnace is specifically engineered for dental. Allowing $\text{zirconia}$ restorations to be placed directly without manual calibration temperature while guaranteeing zero metal ion contamination to preserve the final aesthetic and biocompatibility of the prosthesis. Furthermore, to proactively safeguard the aesthetic integrity of every restoration and prevent common surface defects, the system incorporates proprietary Zirconia Pre-Drying Technology, which automatically eliminates residual moisture before the sintering cycle. Finally, overall operational reliability is significantly enhanced by an advanced low-voltage drive, a measure implemented to reduce the thermal load on the heating elements and thereby maximize their service life and system uptime.

HeyTemp T1S Zirconia Sintering Furnace

Silicon Carbon*5
Fast/slow sintering model integrated
80 units/90 mm*2 crucibles
Max temperature in 1550°C
Once the sintering time is 2-4 hours

HeyTemp T2S Zirconia Sintering Furnace

Silicon Carbon*4
Fast sintering model
10-20 units/60mm*1 crucible
Max temperature in 1530°C
Once the sintering time is only 1 hour

HeyTemp T3S Zirconia Sintering Furnace

Silicon molybdenum*4
Slow sintering model
150 units/150mm*3 crucibles
Max temperature in 1750°C
Once the sintering time is 4 hours

HeyTemp Zirconia Sintering Furnace Parameter


Model	T1S	T2S	T3S
Voltage	110-120V	110-240V	110-120V
Power	2800W	1200W	4600W
Max Temperature	1550°C	1530°C	1750°C
Heating Rod	Silicon Carbon*5	Silicon Carbon*4	Silicon Molybdenum*4
Rod Lifespan	300 Times	300 Times	500 Times
Heating Rate	200°C/min	200°C/min	100°C/min
Capacity	80units	10-20units	150units
Crucible	90mm*2	60mm*1	100mm*3
Crucible Lifespan	100 Times	100 Times	100 Times
Sintering Model	Fast/Standard Double Model	Fast	Standard
Sintering Time	2-4 Hours	1 Hours	4 Hours
Languages	EN/ES/RU	EN/ES/RU	EN/ES/RU

Explore More Dental Furnaces

Lodden Dental Press Furnace

Explore More

HeyTemp TP Series Porcelain Furnace

Explore More

CAM HeyTemp TS Series Zirconia Sintering Furnace Solution
