Dental 3D Printer & Resin – Lodden dental

Dental Resins for 3D Printer

yankos — Mon, 27 Oct 2025 10:45:26 +0000

Dental Resins for 3D Printer

Dental Casting Resin

Denture Base Resin

Dental Tray Resin

Ortho Model Resin

Gingiva Mask Resin

Removable Model Resin

Surgical Guide Resin

Temporary Restoration Resin

Different Between Commercial

Dentist-Grade Printing Resin

Strength: Must demonstrate high requirements for printing accuracy, flexural strength, and tensile strength to withstand clinical loads
Biocompatibility: Required to ensure patient safety and minimize adverse reactions upon contact with bodily tissues.
Certification: Must possess FDA/CE Medical Certification or equivalent to be legally used for medical devices.

Generic Commercial Printing Resin

Strength: No additional mandatory requirements are enforced for printing accuracy, flexural strength, or tensile strength.
Biocompatibility: Not a compulsory requirement, making them unsuitable for intraoral applications.
Certification: Typically holds only generic commercial certifications, rendering them non-compliant for medical use.

Lower-odor Solutions

By adopting Water Washable $3\text{D}$ Printing Resins, the post-processing workflow is significantly simplified, demanding less specialized handling than traditional resins. This material also features a considerably reduced odor profile, resulting in a safer and more pleasant laboratory environment.

Ortho Model Resin

High temperature resistance
Wear resistance
High molding speed
High forming precision
Water washable and IPA clean optional
Glay and almond colors optional
500g and 1000g optional

Temporary Restoration Resin

High flexural tensile strength
Wear resistance
Low water absorption
A1, A2, A3, and white colors optional, and customizable
500g and 1000g optional

Removable Model Resin

IPA clean and water-washed optional
High molding speed
High accuracy
Light gray, almond optional, and customizable
500g and 1000g optional

Dental Casting Resin

Offering minimal ash and residue
High accuracy
Low Shrinkage
Fast process
500g and 1000g optional

Gingiva Mask Resin

Flexibable
High accuracy
Tear resistance
Red, pink, pink purple optional and customizable
500g and 1000g optional

Denture Base Resin

Flexible optional
Durable
Use lifespan in 1-3 years
Class II biocompatible
500g and 1000g optional

Surgical Guide Resin

High flexural strength
High accuracy
Transparent
Biocompatible
500g and 1000g optional

Dental Tray Resin

Durable
High accuracy
High flexural strength
Gray, aqua, skin colors optional, and customizable
500g and 1000g optional

Dental Resin One-stop Solution

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":70,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":35,"sizes":[]},"_id":"4b66d24","__dynamic__":{"hotspot_link":"[elementor-tag id=\"add7701\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22taxonomy%22%2C%22taxonomy_id%22%3A%2283%22%7D\"]"},"hotspot_label":"","hotspot_link":{"url":"","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":70,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":79,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"add7701\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22taxonomy_id%22%3A%2283%22%2C%22post_id%22%3A%2218482%22%7D\"]"},"_id":"17ecf76","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/natrueart-stain-and-glaze-paste\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":86,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":35,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"add7701\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22taxonomy_id%22%3A%2283%22%2C%22post_id%22%3A%2221160%22%7D\"]"},"_id":"3b88950","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/dental-lab-polishing-tools\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":86,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":80,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"add7701\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22taxonomy_id%22%3A%2283%22%2C%22post_id%22%3A%229114%22%7D\"]"},"_id":"5ca53f3","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/uv02-uv-curing-machine\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null}],"hotspot_sequenced_animation":"no","tooltip_position":"top","tooltip_trigger":"click","tooltip_animation":"e-hotspot--fade-in-out"}" data-widget_type="hotspot.default">

The post Dental Resins for 3D Printer appeared first on Lodden dental.

UV02 UV Curing Machine

chris@lddentallab.com — Mon, 18 Nov 2024 09:49:02 +0000

365nm, 385nm and 405nm UV light work independently which could cure different resins at the same time, and to achieve more completely post-curing .

The post UV02 UV Curing Machine appeared first on Lodden dental.

CD-X3 Ultrasonic cleaning machine

chris@lddentallab.com — Mon, 18 Nov 2024 09:46:50 +0000

One button automatic Dual-acoustic wave deoxygenation cleaning

The post CD-X3 Ultrasonic cleaning machine appeared first on Lodden dental.

Dental 3D Printer – D Series

chris@lddentallab.com — Mon, 18 Nov 2024 09:07:19 +0000

Dental 3D Printers - D Series

Special Design For Dental

Accuracy<29μm
Special design for dental

Heating Uniformity
Medical Quality

Compatible Multiple Dental Resins

Special Design For Dental Software
Dental Algorithm Optimization

Special Design For Dental

Precision Printing

Utilizes a sophisticated reflective system to distribute LED light with exceptional uniformity across the LCD panel. The light source uniformity of up to 95% ensures consistent and even exposure across the entire build platform for every print job.

High Accuracy & Robust

Effectively minimizes Z-axis oscillation (wobble) during the critical printing process, directly resulting in a significant enhancement of both surface finish quality and overall part accuracy.

3D Dental Software

Special Dental Software

The Lodden Dental $3\text{D}$ Printer operates using a proprietary software platform that has been independently developed and calibrated specifically for the unique demands of digital dentistry.

Easy To Use

This specialized application is engineered to simplify the operator’s workflow, notably through the inclusion of Automated Dental Nesting (Layout) functionality. This intelligent feature efficiently arranges multiple dental parts on the build platform, ensuring optimal resin consumption and maximum printing throughput.

Preconfigured Resin Parameter

The software comes pre-configured with validated printing parameters for the majority of mainstream dental resins on the market. This comprehensive library of preset profiles ensures accurate and consistent results from the first print. Crucially, to maintain an open and flexible system, the software also grants users the ability to manually add and customize parameters for any additional or specialty resins, thereby accommodating future material innovations and personalized preferences.

Optimized Algorithmic Precision

Pixel Algorithm Compensation

A dedicated compensation feature is employed at the pixel level to account for and correct dimensional inconsistencies inherent to the complex geometry of dental anatomy, ensuring superior lateral $X\text{-}Y$ accuracy.

Dedicated Z-Axis Algorithm Compensation

A separate, specialized algorithm actively manages vertical shrinkage and layer depth during curing. This ensures the precise and consistent dimensional integrity of the model’s vertical axis.

Different Of Commercial

Dental 3D Printer

Accuracy: <100μm
Print Quality Control: Requires rigorous light intensity calibration to maintain light uniformity above %95 for consistent layer exposure.
Structural Stability: Dedicated Dental Software incorporating specialized dental optimization algorithms for superior model integrity.
Software Optimization: Dedicated Dental Software incorporating specialized dental optimization algorithms for superior model integrity.

Commercial

Accuracy: >120μm
Print Quality Control: Calibration is not required, resulting in unpredictable light uniformity and variable print quality.
Structural Stability: Relies on less stable mechanisms, such as a T-screw, leading to mechanical instability and compromised surface finish.
Software Optimization: Generic Commercial Software that lacks any specialized algorithms for correcting dental geometry or shrinkage.

Dental 3D Printer Resins

Explore More

UV02 UV Curing Machine

Explore More

Dental 3D Printer - D Series Prameter


Model	D158	D160	DJ89 Plus
X/Y-axis Accuracy	62µm	62µm	29µm
Resolution	2560*1440	2560*1440	7680*4320
Import	Disk/WIFI	Disk/WIFI	Disk/WIFI
Operation System	Win7 or above X64, Mac	Win7 or above X64, Mac	Win7 or above X64, Mac
Screen	5 inch	5 inch	5 inch
Molding Chamber Heating	20-45°C	20-45°C	20-45°C
Light Source Configuration	High power DLP module(wavelength 405nm)	High power DLP module(wavelength 405nm)	UV integrated lamp bead(wavelength 405nm)
Print Speed	1-4S/layer	1-4S/layer	1-4S/layer
layer Thickness	25-100µm	25-100µm	1-100µm
Resin	Castable Wax Resin, Dental model resin, Common Rigid Photosensivie Resin, Standard Resin, Hight hardness, High toughness, Biocompatible Resin

Dental 3D Printer One-stop Soltion

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":53,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":38,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"e07f40f\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22post_id%22%3A%229114%22%7D\"]"},"hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/uv02-uv-curing-machine\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":53,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":82,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"e07f40f\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22post_id%22%3A%228933%22%7D\"]"},"_id":"e03f32c","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/desktop-3d-scanner-for-dental-labs\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":71,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":38,"sizes":[]},"__dynamic__":[],"_id":"fca34ab","hotspot_label":"","hotspot_link":{"url":"","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":71,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":82,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"e65a4c8\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22post_id%22%3A%2218482%22%7D\"]"},"_id":"2f0bbcc","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/natrueart-stain-and-glaze-paste\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":87,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":38,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"39497f8\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22post_id%22%3A%2221160%22%7D\"]"},"_id":"052dd59","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/dental-lab-polishing-tools\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null},{"hotspot_tooltip_content":"

Add Your Tooltip Text Here<\/p>","hotspot_offset_x":{"unit":"%","size":87,"sizes":[]},"hotspot_offset_y":{"unit":"%","size":83,"sizes":[]},"__dynamic__":{"hotspot_link":"[elementor-tag id=\"39497f8\" name=\"internal-url\" settings=\"%7B%22type%22%3A%22post%22%2C%22post_id%22%3A%229111%22%7D\"]"},"_id":"1014e01","hotspot_label":"","hotspot_link":{"url":"https:\/\/www.loddendental.com\/en\/product\/cd-x3-ultrasonic-cleaning-machine\/","is_external":"","nofollow":"","custom_attributes":""},"hotspot_icon":{"value":"","library":""},"hotspot_custom_size":"no","hotspot_horizontal":"left","hotspot_vertical":"top","hotspot_tooltip_position":"no","hotspot_position":null,"hotspot_icon_position":null,"hotspot_icon_spacing":null,"hotspot_width":null,"hotspot_height":null,"hotspot_tooltip_width":null,"hotspot_tooltip_text_wrap":null}],"hotspot_sequenced_animation":"no","tooltip_position":"top","tooltip_trigger":"click","tooltip_animation":"e-hotspot--fade-in-out"}" data-widget_type="hotspot.default">

The post Dental 3D Printer – D Series appeared first on Lodden dental.
